CSF TWIN CHARGE-AIR-COOLER SET

BMW F10 M5 TWIN CHARGE-AIR-COOLER SET (CSF-8109)

World’s 1st cast end tank designed high performance charge-air-cooler set for the BMW F10 M5

Custom designed CSF liquid-to-air intercooler core (CFD analysis and testing completed to ensure optimal performance)

28% increase in core size per each charge cooler compared to the OEM charge air coolers.

Top/bottom, cross-flow, dual-pass core configuration with2-stage water cooling for maximum efficiency and intake temperature reduction

Designed with 3D scanning / rapid prototype technology to ensure precise fitment and maximum surface area utilization.

“Drop-in fit” design for an easy & quick plug-and-play installation. Complete with OEM style “Quick-Connect” water connections and sensor ports.

Additional E85/methane injection ports built into the cast end tank design

Finished with a professional “Crinkle Black” powder coat finish (CSF-8109). Also available in raw aluminium finish with option for custom powder coating available (inquire for more details on lead time and pricing)
